Product Overview
This Network Extender is a product extends 4K@60Hz signal for 70 meters cover Cat5e or Cat6 cable. The extender supports long-distance transmission, low power consumption, low radiation and more safer. The Transmitter and Receiver are 2 in 1. The function can be switched between by pressing the switch button. It also supports audio extraction.
Video
HDMI and HDCP: HDMI2.0; HDCP2.2
Bandwidth: 18Gpbs
Maximum resolution: 3840x2160@60Hz
Interface: HDMI-A Interface
Cascade: 8 units
IR control
Interface: 3.5mm socket
Signal direction: Two-way transmission
Signal types: digital signals
Frequency: 20 - 60 Khz
Audio
3.5 left and right audio channels: Stereo 2.0
Stereo support: 2.0 stereo ch analog
Support compressed audio: DTS Digital, Dolby Digital, DTS-HD Dolby TrueHD
Other
Power adaptor: DC12V - 24V
Max power: Receiver 9W/ Transmitter 9W
Working temperature: -5° C ~ +70° C
Working humidity: 5% ~ 90%
size: 112*79*28mm
